KT88

Tetrode · IHT · Octal · 1956

Commanding authority.

Beam power tetrode rated at 35W for high-power output stages

Datasheet ↗SPICE
TRANSCONDUCTANCE0mA/V
Cgk0pF
Cgp0pF
Cpk0pF
GAIN0%
POWER88%
DRIVE50%
LINEARITY75%
HEATER6.3V / 1.6A
MAX PLATE800V / 35W
BASEoctal
EXECUTIVE SUMMARY

The KT88 is a beam tetrode developed by GEC/Marconi-Osram (MOV) in 1956, designed specifically for high-power audio amplifier service with a plate dissipation of 42W. It produces 50W or more per pair in push-pull with a sound that combines the linearity of a triode with the power and efficiency of a beam tetrode, delivering tight bass, controlled dynamics, and a somewhat neutral tonal balance. The KT88 is the output tube of the legendary Dynaco Mark III, McIntosh MC275, and many other classic amplifiers. Original GEC KT88s are among the most valuable NOS audio tubes; Gold Lion (Genalex reissue), Shuguang, and JJ produce current alternatives of varying quality.

APPLICATIONS
High-power output
Dynaco Mark IIIMcIntosh MC275Audio Research VT100
Guitar amp PA/public address
VS 6550
HISTORY
Introduced1956ManufacturerGECEquivalents6550
Golden Age
SPECIFICATIONS
Heater Voltage6.3V
Heater Current1.6A
Max Plate Voltage800V
Max Power35W
Sensitivity11.5 mA/V
Gain Factor
Internal Impedance
PinoutOctal
Era1956
RaritySought-after
Input Capacitance14pF
Miller Capacitance0.8pF
Output Capacitance10pF
PDF

KT88 Datasheet

Frank's Electron Tube Pages · PDF
